• Two Speed
• 12 & 3 O'clock Conduit Entries
• 3-1/2" Shaft Height
• 50°C Ambient
• Four Thru Bolts on a 5.146 Bolt Circle
• Flex 48 LASAR XL for Extra Low Running Amps
• Threaded Shaft
• Rigid Base
• Energy Efficient
• Meets California Energy Commission Appliance Regulations 2008

Specifications:

• Phase: 1
• Output HP: 3-.38 Hp
• Output KW: 2.2 kW
• Voltage: 230 V
• Speed: 3450/1725 rpm
• Service Factor: 1
• Frame: Y48Y
• Enclosure: Drip Proof
• Thermal Protection: Thermally Protected
• Ambient Temperature: 50 °C
• Frequency: 60 Hz
• Current: 12.0/3.5 A
• Duty: Continuous
• Insulation Class: F
• UL: Recognized
• CSA: Y
• Number of Speeds: 2-2-VT
