• Two Speed
• 12 & 3 O'clock Conduit Entries
• 3-1/2" Shaft Height
• 40°C Ambient
• Four Thru Bolts on a 5.146 Bolt Circle
• Flex 48 LASAR Line Low Amp Start and Run with 48/56 Base Mounting
• 48/56 Base Mounting
• Threaded Shaft
• Rigid Base

Specifications:

• Phase: 1
• Output HP: 2-.25 Hp
• Output KW: 1.5 kW
• Voltage: 230 V
• Speed: 3450/1725 rpm
• Service Factor: 1
• Frame: X48Y
• Enclosure: Drip Proof
• Thermal Protection: Thermally Protected
• Ambient Temperature: 40 °C
• Frequency: 60 Hz
• Current: 10.5/2.6 A
• Duty: Continuous
• Insulation Class: F
• UL: Recognized
• CSA: Y
• Number of Speeds: 2-2-VT

Unable to sell or install this product in New York or California.
